SALIENT FEATURES OF TANK TERMINAL
Terminal Storage Capacity:
70,000 MT
Numbers of Tank:
14
Capacity of each Tank:
5,000MT
Diameter of Tank:
24.50 Meter
Height of Tank:
12.74 Meter
Size of Pipeline:
Reception line RM-5,6,7 to Tanks: 10 inch
Delivery line:
8-10 inch
Pump Capacity (2 X each 200):
400 MT/Hr.
Fire Fighting System:
Foam Injection
Fire Water Network:
Hydrants
Standby Generator:
450 KVA
CODES AND STANDARDS COMPLIED
Petroleum Rules
1937
Tank Design Code:
API 650
Steel Plate:
ASTM A283 Gr. C/A36
Structural Steel:
ASTM A36
Pipe:
ANSI B31.3
Welding Fittings:
ASTM A234 Gr.WPB, ANSI B16.9
Slip on Fanged:
ASTM A 105 or ANSI B16.9
Stud-Bolt:
ASTM A193-B7
Fire Fighting Equipment:
NFPA-30
Department of Explosives has given approval of the project in accordance with the provision of Petroleum Rules, 1937
